TeeBI Web Server returning a summary chart

TeeBI teaser

Small teaser of TeeBI.

This is the custom web server calculating a query and returning a chart. The only dependencies are TeeChart and Indy http web server component.

TeeBI Web Server returning a summary chart



Data is in column-oriented, memory-based custom format for speed reasons, no database or FireDac, etc are necessary. Data is imported from many sources (excel, text files, firedac or any other datasets, etc) to the custom format, which is then transparent to the user apps.

The web server is optional if data is not remote, and it can also return binary streams to normal desktop (vcl or fmx), or mobile apps (fmx).

A table of 2000×5 cells takes 180msec via web. For visual display, an fmx or vcl dbgrid easily handles 1 or more million rows with a custom “TBIDataset” linked to an in-memory data, allowing grouping, filtering and sorting using complex expressions involving columns from the same table or foreign-key(s) fields.

This speed is the basis for a next-coming set of machine-learning and data-mining algorithms, currently under development.



Read More

Reaching the browser page with TeeChart

How different versions of TeeChart reach the browser page



Recent news that Microsoft are ceasing support for ActiveX with the new navigator, Edge, included with Windows 10, seems to signal the end of mainstream browser support for ActiveX.

ActiveX support was one of the flagship functionality elements for Internet Explorer some years ago but security policies of many organisations, in response to reports of possible intruder exploitation of some aspects of some ActiveX controls, have meant that many applications using ActiveX components have shifted off the browser completely or that browser apps have moved to different formats such as ASP.NET, Java Applets or Javascript/HTML5.

Security clearance for TeeChart ActiveX Control in Internet Explorer

Quite some time ago Steema Software worked extensively with some key customers and CERT (https://www.us-cert.gov/) certification, using their recommendations and analysis tools to make sure that any possible entry points to TeeChart were closed-off. As such, here at Steema we don’t consider TeeChart to offer security weakpoints, but nevertheless, the industry has steadily moved away from ActiveX on the browser and alternative options already needed to be studied as far back as multiple years ago.

This article discusses some of the current options available.

Static Charts on the browser page

All versions of TeeChart are able to work as a serverside component and to generate a static, rendered image of a chart in response to any dynamic input, request or web form post. The response can be quick and effective. Though a static chart offers no interactivity to the person using the application, interactivity is not always necessary or desirable and a static chart has its place as a valid browser page format.

Interactive Charts on the browser page

Interactive Charts on the browser page permit persons using the application to work with the chart, changing its view via a zoom or scroll, or permitting a click/touch on a chart to return more information or insight or to provoke a drill-down in search of more detailed information.

The following sections describe what each version of TeeChart has to offer in terms of interactive charting functionality on the browser.



TeeChart for .NET – ASP.NET and WebForm applications

TeeChart for .NET offers a WebChart for placement on a Webform.  The chart is editable via the chart editor at designtime in the Visual Studio IDE and can be run with several interactivity modes:

  • Static Chart; the rendering of a png, jpg or gif format Chart in response to an ASP.NET page query. No interactivity experience for the user other than that offered by external options around the chart such as a combo selection to generate a new chart or view.
  • Interactive Ajax powered Javascript Chart; interaction for mouseclicks locally on page or for drilldown (postback) to server. Charts can be zoomed by mouse or scrolled via a scrollbar. Javascript on the page permits a variety of enhancements to affect how the chart reacts to interaction. User experience for interaction at this level is of a moderate to good level.
  • Interactive HTML5 Canvas powered Chart. The designtime editing options remain the same as for previous options but the chart is rendered on a fully interactive HTML5 Javascript powered Canvas that allows pageside javascript to control some aspects of the charting experience and for others to be fed back to the serverside module. Not all TeeChart for .NET’s Series types can be rendered to the HTML5. User experience in terms of interactivity is of a very high level as the HTML5 chart is a live component on the page with full access at runtime to the TeeChart for Javascript charting library.



TeeChart for Javascript, HTML5 applications

TeeChart for Javascript is a pure-for-the-web-browser designed Component. This version of TeeChart, also referred to as TeeChart for HTML5, requires to be designed by an HTML page designer with facility to edit on-page Javascript (notepad will do) and offers a very high level of interactivity to the browser page viewer as the chart is fully live in the page with dynamic access to the full TeeChart for HTML5 component library. HTML5 charts can reach virtually any platform as nearly all current browsers natively support Javascript and the HTML5 canvas.



TeeChart in HTML5. Live zoom/scroll/click
TeeChart for Javascript/HTML5.

TeeChart for Java, Servlet and Applet applications

TeeChart for Java powered web browser applications may be viewed on the browser page as a Java applet. A Java applet is, in effect, a standalone application on the browser page and offers functionality and a way of working, similar in many respects to the TeeChart ActiveX control. Applet support in the browser is in decline and appears to be going the same way as ActiveX Control support as many organisations add restrictions to the technology types they are willing to support on browser platforms. More recent versions of browsers have imposed further security restrictions demanding code-signing of controls that are allowed to be run on the browser page. If you decide to start a new project using Java Applets as the means to take TeeChart to the browser page, we recommend you check first, the current situation for browser support and certification requirements.

A Java servlet runs at the server and is able to return static Charts as images to client browser applications in response to dynamic requests.



TeeChart for VCL

TeeChart for VCL can reach the browser with a fully interactive Chart via Delphi’s ActiveForm technology. As ActiveForm is an ActiveX control, support for it will be dropped from the Edge browser included with Windows 10 so we recommend you confirm the browser platform to be used before starting new development projects for that environment with it.

TeeChart for VCL also supports export to HTML5, thus offering fully live charts on the browser page. Export is supported for a limited set of Series types only.



TeeChart for PHP

TeeChart for PHP is designed to respond to dynamic requests at a web server to provide charts in static or dynamic formats. The current supported dynamic format is HTML5 and TeeChart for PHP works in unison with TeeChart for HTML5 to create a javascripted clientside, fully interactive chart.



TeeChart for ActiveX, ASP applications

TeeChart for ActiveX has been discussed at the opening of this article. It is a very powerful way to deliver a web application to a browser, being similar in nature to a desktop application on the browser page. ActiveX has only ever been supported on Internet Explorer (apart from some addins available in the past for other browsers) which limits its public a little. The phasing out of support for ActiveX for the default browser, Edge, in Windows 10 means that it is probably best avoided when considering developing new browser applications going forward. TeeChart for ActiveX remains an extremely useful tool for virtually all other COM compatible containers and can be used to create static charts for the browser page with javascript enhancements for hotspots.

Alternatively the TeeChart for ActiveX version may still be used to generate live, interactive charts in HTML5 for virtually all browsers. Note that HTML5 export is supported for a limited set of Series types only.

Read More

Delphi Gestures with TeeChart

Since Embarcadero introduced touch screen support, the way gestures are being handled has evolved. Now that we are in the RAD Studio XE8 days, it has become pretty straightforward as documented in their “Gesturing Overview” article.

DelphiGestures

That article lays out the foundation on how to work with touch gestures and controls. Applying that to TeeChart, means we’ll need TChart and TGestureManager components. TGestureManager, which manages all the gestures that can be used by the control, will have to be associated to TChart’s Touch property. There you can choose which gestures will be associated with the control. There are three kinds of gestures: standard, custom and interactive. The example discussed is based on Delphi’s interactive gestures example.

Here you can download the full project used for the article. Now I’ll explain how to create it. Before starting to write code, please do the following at design-time: add a TChart component, add a TGestureManger component, passing the gesture manager to TChart‘s Touch property and enable Zoom, Pan and DoubleTap interactive gestures on it.

Once this is done, it’s time to start typing code. First of all we’ll deactivate some TeeChart standard interactions so they don’t interfere with the functionality gestures will implement. So we will disable default zoom and panning in form’s OnCreate event:

procedure TForm1.FormCreate(Sender: TObject);
var
  Series1: TSurfaceSeries;
begin
  Series1 := TSurfaceSeries.Create(Self);
  Series1.FillSampleValues(10);
  Series1.UseColorRange := False;
  Series1.UsePalette := True;
  Series1.PaletteStyle := psStrong;

  Chart1.AddSeries(Series1);
  Chart1.Zoom.Allow := False;
  Chart1.Panning.Active := False;
  Chart1.Chart3DPercent := 50;

  with TFlatTheme.Create(Chart1) do
  try
    Apply;
  finally
    Free;
  end;
end;

After that, it’s the turn of TChart‘s OnGesture event implementation:

procedure TForm1.Chart1Gesture(Sender: TObject;
  const EventInfo: TGestureEventInfo; var Handled: Boolean);
begin
  if EventInfo.GestureID = igiZoom then
    handleZoom(EventInfo)
  else if EventInfo.GestureID = igiPan then
    handlePan(EventInfo)
  else if EventInfo.GestureID = igiDoubleTap then
    handleDoubleTap(EventInfo);

  Handled := True;
end;

We are checking for TInteractiveGestures gestures performed on the chart, using event’s TGestureEventInfo, and implement a specific gesture handler method for each one. Finally, we set the Handled parameter to True so that the event is not propagated further.

Let’s speak about gesture handler methods now, starting with zoom:

procedure TForm1.handleZoom(EventInfo: TGestureEventInfo);
var
  LObj: IControl;
  chart: TChart;
  zoom: Double;
begin
  LObj := Self.ObjectAtPoint(ClientToScreen(EventInfo.Location));
  if LObj is TChart then
  begin
    if not(TInteractiveGestureFlag.gfBegin in EventInfo.Flags) then
    begin
      chart := TChart(LObj.GetObject);
      zoom := (EventInfo.Distance / FLastDIstance) * chart.Aspect.ZoomFloat;
      chart.Aspect.ZoomFloat := Max(10, zoom);
    end;
  end;
  FLastDIstance := EventInfo.Distance;
end;

Here we are implementing something different and simpler than the standard zoom in TeeChart. It’s based on the difference between the current distance and pinch that the gesture provides and the distance saved from previous calls, not allowing a zoom factor smaller than 10% of the original size.

Let’s continue with the pan gesture which, in this example, will be used for rotating the chart instead of panning it:

procedure TForm1.handlePan(eventInfo: TGestureEventInfo);
var
  LObj: IControl;
  chart: TChart;
begin
  LObj := Self.ObjectAtPoint(ClientToScreen(EventInfo.Location));
  if LObj is TChart then
  begin
    if not(TInteractiveGestureFlag.gfBegin in EventInfo.Flags) then
    begin
      chart := TChart(LObj.GetObject);

      chart.Aspect.Orthogonal := False;
      chart.Aspect.RotationFloat := chart.Aspect.RotationFloat + (EventInfo.Location.X - FLastPosition.X);
      chart.Aspect.ElevationFloat := chart.Aspect.ElevationFloat - (EventInfo.Location.Y - FLastPosition.Y);
    end;

    FLastPosition := EventInfo.Location;
  end;
end;

Similar to the pinch zoom gesture, here displacement (calculated from the screen position) is being used to rotate and elevate the chart.

Finally, the double tap gesture:

procedure TForm1.handleDoubleTap(eventInfo: TGestureEventInfo);
var
  LObj: IControl;
begin
  LObj := Self.ObjectAtPoint(ClientToScreen(EventInfo.Location));
  if LObj is TChart then
    ResetChart(TChart(LObj.GetObject));
end;

procedure TForm1.ResetChart(chart: TChart);
begin
  chart.Aspect.Orthogonal := True;
  chart.Aspect.ZoomFloat:=100;
  chart.Aspect.ElevationFloat:=345;
  chart.Aspect.RotationFloat:=345;
end;

It’s only used for resetting chart properties to their original values.

I hope this example is useful to illustrate the possibilities TeeChart has with multi-touch gesture on touch devices. It only covers a few cases but this opens up the possibility to a new world of charting interactions.

Here’s the complete code listing for the example discussed in this article:

unit Unit1;

interface

uses
  System.SysUtils, System.Types, System.UITypes, System.Classes, System.Variants,
  FMX.Types, FMX.Controls, FMX.Forms, FMX.Graphics, FMX.Dialogs,
  FMX.Controls.Presentation, FMX.StdCtrls, FMXTee.Engine, FMXTee.Procs,
  FMXTee.Chart, FMXTee.Series, FMXTee.Commander, FMX.Gestures,
  FMXTee.Series.Surface, FMXTee.Themes;

type
  TForm1 = class(TForm)
    Chart1: TChart;
    GestureManager1: TGestureManager;
    procedure FormCreate(Sender: TObject);
    procedure Chart1Gesture(Sender: TObject; const EventInfo: TGestureEventInfo;
      var Handled: Boolean);
  private
    { Private declarations }
    FLastPosition: TPointF;
    FLastDistance: Integer;
    procedure handleZoom(eventInfo: TGestureEventInfo);
    procedure handlePan(eventInfo: TGestureEventInfo);
    procedure handleDoubleTap(eventInfo: TGestureEventInfo);
    procedure ResetChart(chart: TChart);
  public
    { Public declarations }
  end;

var
  Form1: TForm1;

implementation

{$R *.fmx}

uses System.Math;

procedure TForm1.Chart1Gesture(Sender: TObject;
  const EventInfo: TGestureEventInfo; var Handled: Boolean);
begin
  if EventInfo.GestureID = igiZoom then
    handleZoom(EventInfo)
  else if EventInfo.GestureID = igiPan then
    handlePan(EventInfo)
  else if EventInfo.GestureID = igiDoubleTap then
    handleDoubleTap(EventInfo);

  Handled := True;
end;

procedure TForm1.FormCreate(Sender: TObject);
var
  Series1: TSurfaceSeries;
begin
  Series1 := TSurfaceSeries.Create(Self);
  Series1.FillSampleValues(10);
  Series1.UseColorRange := False;
  Series1.UsePalette := True;
  Series1.PaletteStyle := psStrong;

  Chart1.AddSeries(Series1);
  Chart1.Zoom.Allow := False;
  Chart1.Panning.Active := False;
  Chart1.Chart3DPercent := 50;

  with TFlatTheme.Create(Chart1) do
  try
    Apply;
  finally
    Free;
  end;
end;

procedure TForm1.handleDoubleTap(eventInfo: TGestureEventInfo);
var
  LObj: IControl;
begin
  LObj := Self.ObjectAtPoint(ClientToScreen(EventInfo.Location));
  if LObj is TChart then
    ResetChart(TChart(LObj.GetObject));
end;

procedure TForm1.handlePan(eventInfo: TGestureEventInfo);
var
  LObj: IControl;
  chart: TChart;
begin
  LObj := Self.ObjectAtPoint(ClientToScreen(EventInfo.Location));
  if LObj is TChart then
  begin
    if not(TInteractiveGestureFlag.gfBegin in EventInfo.Flags) then
    begin
      chart := TChart(LObj.GetObject);

      chart.Aspect.Orthogonal := False;
      chart.Aspect.RotationFloat := chart.Aspect.RotationFloat + (EventInfo.Location.X - FLastPosition.X);
      chart.Aspect.ElevationFloat := chart.Aspect.ElevationFloat - (EventInfo.Location.Y - FLastPosition.Y);
    end;

    FLastPosition := EventInfo.Location;
  end;
end;

procedure TForm1.handleZoom(EventInfo: TGestureEventInfo);
var
  LObj: IControl;
  chart: TChart;
  zoom: Double;
begin
  LObj := Self.ObjectAtPoint(ClientToScreen(EventInfo.Location));
  if LObj is TChart then
  begin
    if not(TInteractiveGestureFlag.gfBegin in EventInfo.Flags) then
    begin
      chart := TChart(LObj.GetObject);
      zoom := (EventInfo.Distance / FLastDIstance) * chart.Aspect.ZoomFloat;
      chart.Aspect.ZoomFloat := Max(10, zoom);
    end;
  end;
  FLastDIstance := EventInfo.Distance;
end;

procedure TForm1.ResetChart(chart: TChart);
begin
  chart.Aspect.Orthogonal := True;
  chart.Aspect.ZoomFloat:=100;
  chart.Aspect.ElevationFloat:=345;
  chart.Aspect.RotationFloat:=345;
end;

end.

Read More

Check out the new StandardSeriesDemo example

Check out the new StandardSeriesDemo example which has been created for most of the Steema TeeChart products.

You can download and check the source code for each TeeChart version at the Steema GitHub page :

https://github.com/Steema/TeeChart-for-.NET-CSharp-WinForms-samples/tree/master/StandardSeriesDemo (for TeeChart for NET WinForms -CSharp).

https://github.com/Steema/TeeChart-for-FireMonkey-applications-samples/tree/master/StandardSeriesDemo (for TeeChart for FireMonkey FMX).

https://github.com/Steema/TeeChart-ActiveX-samples/tree/master/StandardSeriesDemo (for TeeChart ActiveX).

https://github.com/Steema/teechart-xamarin-foms-samples/tree/master/StandardSeriesDemo (for TeeChart for Xamarin.Forms).

https://github.com/Steema/TeeChart-Java-for-Swing-applications-samples/tree/master/StandardSeriesDemo (for TeeChart for Java).

StandardSeriesDemo1 StandardSeriesDemo2 StandardSeriesDemo3 StandardSeriesDemo4



Read More

Generic Delphi Tree structure

A generic Tree structure made in Delphi is freely available at this GitHub repository:

https://github.com/davidberneda/GenericTree

See the readme at GitHub for details and updated documentation.

This small class allows creating hierarchical structures where each “node” is a small object (20 bytes plus your own data size), containing a property of your desired type.

For example, a Tree of string nodes:

var MyTree : TNode<String>;

MyTree.Data :=’hello’;







Read More

Clustering visualization

TeeChart Pro includes classes and components to perform “clustering” on your data, and optionally visualize the results using a chart “Tool” component.

Clustering is the process of grouping data automatically, according to how well related are the individual items.

As an unsupervised algorithm, its widely used in data-mining / machine-learning / B.I. (Business Intelligence) applications.



teechart_clustering

For more information on clustering visit the following Wikipedia link: http://en.wikipedia.org/wiki/Cluster_analysis

An executable example:

http://www.steema.us/files/public/teechart/vcl/demos/clustering/TeeChart_Clustering.zip

The clustering algorithm can be processed on custom data, not necessarily on TeeChart “Series” data.



Classes and Units

The TeeClustering.pas unit, for both VCL and Firemonkey, contains abstract “engine” classes that perform the clustering algorithms.

Three different clustering methods are provided:

• TKMeansClustering

• THierarchicalClustering

• TQTClustering (Quality Threshold)

These classes derive from a common abstract class: TBaseClustering.

Each clustering method has its own properties that determine how will the clusters be calculated. After calculating, you can access the Clusters property, which is a TList of TCluster objects.

A TCluster contains child clusters (Items[ ]), so you can check which input data items belong to which cluster, or in the case of the Hierarchical type, access the tree structure (clusters and sub-clusters).

The input data (your data) is not contained by the above classes.

Data is passed to the clustering engine through a “provider” class. There is currently one kind of data provider (TSeriesProvider) to cluster XY or XYZ Series points.

This class is implemented in the TeeClusteringTool.pas unit, together with a charting Tool class (TClusteringTool) to make things easier and more automatic.



Basic Example

Example runtime code (it can be done at design-time too, without coding) :

uses TeeClusteringTool;

var tool : TClusteringTool;

tool:=TClusteringTool.Create(Self);

tool.ParentChart:=Chart1;

tool.Series:=Series1; // your series

tool.Method:=cmKMeans;

tool.KMeans.NumClusters:=5;

tool.Execute;



After execution, you can loop on the resulting output clusters, for example:

var t : Integer;

for t:=0 to tool.Clusters.Count-1 do
Memo1.Lines.Add( ‘Cluster: ‘+IntToStr(t)+’ contains:  ‘+
IntToStr(tool.Clusters[t].Count)+’ points’ );





TClusteringTool

This tool automatically performs clustering using the choosen method and parameters, and optionally paints each source series point with a different color indicating which cluster they belong to, and/or draws polygons around each group of cluster’s items, among other things.

Properties:

ClusteringTool1.Method := cmHierarchical;

ClusteringTool1.ColorEach := True; // paint Series with one color per cluster

ClusteringTool1.ShowBounds := True; // draws convex polygons bounding each cluster points

ClusteringTool1.Centers.Visible := True; // shows cluster centers

ClusteringTool1.Centroids.Visible := True; // shows cluster centroids

Other properties include Brush, Pen and Transparency, used when drawing cluster polygon boundaries.

Methods:

Several helper methods are provided:

// Obtain cluster’s center and centroid XY points in Series scales:

var P : TPointFloat;

P:=ClusteringTool1.GetClusterCenter( ClusteringTool1.Clusters[3] );

P:=ClusteringTool1.GetClusterCentroid( ClusteringTool1.Clusters[2] );

// Obtain an array of XY points (in screen pixel coordinates), that belong to cluster:

var PP : TPointArray;

ClusteringTool1.GetClusterPoints( ClusteringTool1.Clusters[4], PP);

PP:=nil;

// Get cluster statistics:

var S : TClusterStats;

S:=ClusteringTool1.GetStats( ClusteringTool1.Clusters[0] );



Calculation parameters

Each clustering algorithm needs different parameters:

K-Means:

ClusteringTool1.KMeans.NumClusters := 10; // Number of minimum clusters (“K”)

ClusteringTool1.KMeans.MaxIterations := 1000; // Maximum number of iterations before stopping

Hierarchical:

ClusteringTool1.Hierarchical.NumClusters := 8; // Number of tree root clusters

QT:

ClusteringTool1.QTClustering.MinCount := 30; // Minimum number of points to form a cluster

ClusteringTool1.QTClustering.MaxDiameter := 100; // Maximum “diameter” a cluster can grow



Common parameters:

Distance

Cluster calculation is based on the “distance” between a data item and the other data items. There are several ways to calculate the “distance” between items.

The algorithms are agnostic, they call the Provider (ie: Series provider) to obtain the distances.

For example, on a XY scatter plot, the distance between points can be for example the hypotenuse (Pythagoras’ theorem), that is, the simple Euclidean distance between a point XY and another XY.

Distance calculations implemented:

dmEuclidean
dmSquaredEuclidean
dmManhattan
dmMinkowski
dmSorensen
dmChebyshev



Example:

ClusteringTool1.Distance := dmMinkowski;

ClusteringTool1.MinkowskiLambda := 4;



Linkage

There are several ways to calculate the “distance” between clusters when one or the two clusters have more than one item.

This is called “linkage”.

The most simple way is using each cluster “center” (this means no linkage occurs).

Other linkage styles implemented:

lmSingle

Also called “minimum”.

The distance between cluster A and B is the minimum distance between all items in cluster A and all items in cluster B.

lmComplete

Also called “maximum”.

The distance between cluster A and B is the maximum distance between all items in cluster A and all items in cluster B.

lmAverage

The distance between cluster A and B is the average distance between all items in cluster A and all items in cluster B.

lmWard

The result is the increase on “error sum of squares” when adding cluster B items to cluster A.



Calculation speed

Clustering is a slow process by nature. Each clustering method has different performance bottlenecks, proportional to the number of input data items.

The TeeClustering.pas unit has been greatly fine-tuned to optimize the speed of each algorithm, although much work is needed to find more advanced techniques that require less CPU cycles.

The QT Threshold algorithm benefits of parallelism, when multiple CPUs can be used together.

Speed examples (revisited):

(Time in milliseconds, Windows 8.1 x64 on Intel i7 4770 @ 3.4Ghz)

IDE XE8 Delphi, Win32, 5000 data points

Algorithm      Single CPU   Multiple CPU

K-Means              47                     31
Hierarchical    4328                4156
QT                     2859                  703

Notes:

x64 bit executables are a little bit faster than 32bit.

Speed is also very dependant on the “distance” calculation method that is used to compare data.  The default Euclidean calculation has a quite big CPU cost as it calculates the Hypotenuse between two data XY value pairs.





Read More

DashBoards and Data Visualization using Xamarin.Forms and TeeChart

DashBoards and Data Visualization using Xamarin.Forms and TeeChart

This article is going to show how easy it is to create dashboard designs to show information, especially data, by using the layouts included in Xamarin.Forms and how to use the TeeChart charting library, which fully supports Xamarin.Forms.

In this example several Charts will be added to the layout, choosing a specific design which will be adjusted for each device depending on the platform chosen.

The first step is to create a new Xamarin.Forms application (Portable)
New Project -> Visual C# -> Mobile Apps -> Blank App (Xamarin.Forms.Portable)




Now, we’re going to add the TeeChart for Xamarin.Forms libraries as a reference to our projects to be able to use it.

Find the dlls for each specific platform on your hard disk (at the TeeChart for Xamarin.Forms installation folder). The TeeChart.PCL library also has to be referenced in all the projects.



Adding the TeeChart for Xamarin.Forms library as reference to the project.



TeeChart.PCL for the TeeChartDashBoards Portable project

TeeChart.PCL.Android.dll for the TeeChartDashBoards.Droid project

TeeChart.PCL.iOS.Unified.dll for the TeeChartDashBoards.iOS project

TeeChart.WP8.dll for the TeeChartDashBoards.WinPhone project



In order to make use of the TeeChart charting library we need to create a View which will contain the Chart component on it to be able to add it on our project, this “ChartView.cs” class has to be defined into the main project  (all the platforms will make use of it).



To create, just add a new class to the TeeCahrtDashBoards Portable project and add the following code to it :



using System;
using System.Collections.Generic;
using System.Linq;
using System.Text;
using System.Threading.Tasks;
using Xamarin.Forms;

namespace TeeChartDashBoards
{
public class ChartView: View
{
public ChartView()
{
}

public EventHandler OnInvalidateDisplay;

public static readonly BindableProperty ModelProperty =
BindableProperty.Create(“ModelProperty”, typeof(Steema.TeeChart.Chart), typeof(ChartView), null);

public Steema.TeeChart.Chart Model
{
get { return (Steema.TeeChart.Chart)GetValue(ModelProperty); }
set { SetValue(ModelProperty, value); }
}

public void InvalidateDisplay()
{
if (OnInvalidateDisplay != null)
OnInvalidateDisplay(this, null);
}
}
}





Now, in order to make use of the ChartView, a renderer class is needed for each specific platform, so we’ll create a new class named “ChartViewRenderer.cs” for each platform and add the following code :


This is the code for the Android project :



using System;
using System.Collections.Generic;
using System.Linq;
using System.Text;
using Android.App;
using Android.Content;
using Android.OS;
using Android.Runtime;
using Android.Widget;
using Xamarin.Forms;
using Xamarin.Forms.Platform.Android;
using Steema.TeeChart;
using TeeChartDashBoards;

[assembly: ExportRenderer(typeof(ChartView), typeof(ChartViewRenderer))]
namespace TeeChartDashBoards.Droid
{
public class ChartViewRenderer: ViewRenderer
{
protected TChart NativeControl
{
get
{
return ((TChart)Control);
}
}

protected ChartView NativeElement
{
get
{
return ((ChartView)Element);
}
}

protected override void OnElementChanged(ElementChangedEventArgs<View> e)
{
base.OnElementChanged(e);

if (Control == null)
{
var chartView = new Steema.TeeChart.TChart(Context);

chartView.Chart = NativeElement.Model;

SetNativeControl(chartView);
}

if (e.OldElement != null)
{
//unhook old events
}

if (e.NewElement != null)
{
//hook old events
}
}
}
}



Do the same for the iOS project, adding the following code :



using System;
using System.Collections.Generic;
using System.ComponentModel;
using System.Linq;
using System.Text;
using System.Threading.Tasks;
using Xamarin.Forms;
using Xamarin.Forms.Platform.iOS;
using TeeChartDashBoards;

[assembly: ExportRenderer(typeof(ChartView), typeof(TeeChartDashBoards.iOS.ChartViewRenderer))]
namespace TeeChartDashBoards.iOS
{
public class ChartViewRenderer : ViewRenderer<ChartView, Steema.TeeChart.TChart>
{
protected override void OnElementChanged(ElementChangedEventArgs<ChartView> e)
{
base.OnElementChanged(e);
if (e.OldElement != null || this.Element == null)
return;

var chartView = new Steema.TeeChart.TChart();

chartView.Chart = Element.Model;

SetNativeControl(chartView);
}

protected override void OnElementPropertyChanged(object sender, PropertyChangedEventArgs e)
{
base.OnElementPropertyChanged(sender, e);
}
}
}



and the for the WinPhone project :



using TeeChartDashBoards;
using System;
using System.Collections.Generic;
using System.ComponentModel;
using System.Linq;
using System.Text;
using System.Threading.Tasks;
using Xamarin.Forms;
using Xamarin.Forms.Platform.WinPhone;

[assembly: ExportRenderer(typeof(ChartView), typeof(TeeChartDashBoards.WP8.ChartViewRenderer))]
namespace TeeChartDashBoards.WinPhone
{
public class ChartViewRenderer : ViewRenderer<ChartView, Steema.TeeChart.TChart>
{
protected override void OnElementChanged(ElementChangedEventArgs<ChartView> e)
{
base.OnElementChanged(e);
if (e.OldElement != null || this.Element == null)
return;

var chartView = new Steema.TeeChart.TChart();

chartView.Chart = Element.Model;
chartView.Aspect.ClipPoints = false;
chartView.Aspect.ExtendAxes = true;

SetNativeControl(chartView);
}

protected override void OnElementPropertyChanged(object sender, PropertyChangedEventArgs e)
{
base.OnElementPropertyChanged(sender, e);
}
}
}



At this point, if we do “build solution” all should compile fine.

That being the case, it’s time to create a new Content Page in the main project, the initial page which will appear once the app is launched in one of the available platforms. Set “Home.cs” as the name for the page.

The solution should look like :


Inside this page, the first thing we’ll do is to remove all the code that has been generated by default and will add a code that creates a Navigation page which will allow us to navigate through all the Charts inside the dashboard :



public Home()
{
NavigationPage.SetHasNavigationBar(this, false);
}



Now, we’ll define the layout, choosing the Grid layout that fits our needs. The grid layout allows one to specify the number of rows and columns to show and define the rowspan or colspan if needed (this will allow us to make the dashboard nicer) :



Grid grid = new Grid
{
VerticalOptions = LayoutOptions.FillAndExpand,
Padding = 5,
RowDefinitions =
{
new RowDefinition { Height = new GridLength(1, GridUnitType.Star) },
new RowDefinition { Height = new GridLength(1, GridUnitType.Star) },
new RowDefinition { Height = new GridLength(1, GridUnitType.Star) }
},
ColumnDefinitions =
{
new ColumnDefinition { Width = new GridLength(1, GridUnitType.Star) },
new ColumnDefinition { Width = new GridLength(1, GridUnitType.Star) },
new ColumnDefinition { Width = new GridLength(1, GridUnitType.Star) }
}
};

Content = grid;



Now it’s time to create the Charts that will be added on our dashboard. We’ll add seven Charts. First of all, we’ll create a “DashBoards” folder in the main project to add the content pages there, one for each chart. This folder has to be created one time in the main project (Portable).

Each page will define a specific chart with the Series used on it and its customised appearance. We’ll start with the content page named Page1.cs. We’ll use the following code:



using System;
using System.Collections.Generic;
using System.Linq;
using System.Reflection.Emit;
using System.Text;
using Steema.TeeChart;

using Xamarin.Forms;

namespace TeeChartDashBoards.DashBoards
{
public class Page1 : ContentPage
{
Chart dashBoard0;
public ChartView DashView0;
public Page1()
{
// NavigationPage.SetHasNavigationBar(this, false);

dashBoard0 = new Chart();
dashBoard0.Aspect.View3D = false;
Steema.TeeChart.Styles.Bar bar1 = new Steema.TeeChart.Styles.Bar();
Steema.TeeChart.Styles.Line line1 = new Steema.TeeChart.Styles.Line();
dashBoard0.Series.Add(bar1);
dashBoard0.Series.Add(line1);
//barline chart
bar1.Clear();
bar1.Add(20);
bar1.Add(50);
bar1.Add(10);
bar1.Add(70);
bar1.Add(46);
bar1.Pen.Visible = false;
bar1.BarStyle = Steema.TeeChart.Styles.BarStyles.RectGradient;
bar1.Marks.Visible = false;
bar1.Gradient.StartColor = Color.White;
bar1.Gradient.EndColor = Color.FromRgb(102, 205, 170);
bar1.Marks.Visible = true;
bar1.Marks.Shadow.Visible = false;
bar1.Marks.Color = Color.White;
bar1.Marks.Font.Size = 15;
bar1.Marks.Font.Color = Color.FromRgb(102, 205, 170);
bar1.Marks.Pen.Visible = false;
bar1.Marks.ArrowLength = 5;
bar1.Color = Color.White;

line1.Clear();
line1.Add(0, 45);
line1.Add(0.444444444444444, 55);
line1.Add(0.888888888888889, 75);
line1.Add(1.33333333333333, 65);
line1.Add(1.77777777777778, 45);
line1.Add(2.22222222222222, 80);
line1.Add(2.66666666666667, 85);
line1.Add(3.11111111111111, 98);
line1.Add(3.55555555555556, 75);
line1.Add(4, 68);
line1.Color = Color.FromRgb(255, 255, 240);

line1.LinePen.Width = 3;
line1.Smoothed = true;

dashBoard0.Panel.Color = Color.FromRgb(102, 205, 170);
dashBoard0.Panel.Gradient.Visible = false;
dashBoard0.Walls.Back.Visible = false;
dashBoard0.Title.Text = “Bars and Lines”;
dashBoard0.Title.Alignment = TextAlignment.Start;
dashBoard0.Title.Font.Size = 22;
dashBoard0.Title.Font.Color = Color.White;
//dashBoard0.Title.Font.Name = “”;
dashBoard0.Axes.Left.AxisPen.Visible = false;
dashBoard0.Axes.Bottom.AxisPen.Color = Color.White;
dashBoard0.Legend.Visible = false;
dashBoard0.Axes.Left.Grid.Color = Color.White;
dashBoard0.Axes.Left.Grid.Style = Steema.TeeChart.Drawing.DashStyle.Dot;
dashBoard0.Axes.Left.Labels.Font.Color = Color.White;
dashBoard0.Axes.Bottom.Labels.Font.Color = Color.White;
dashBoard0.Axes.Left.Increment = 25;

DashView0 = new ChartView
{
VerticalOptions = LayoutOptions.FillAndExpand,
HorizontalOptions = LayoutOptions.FillAndExpand,
};
DashView0.Model = dashBoard0;

Content = new StackLayout
{
Children = {
DashView0
}
};
}
}
}



The code above defines a Chart component for the page, adds some series styles to it and then set some custom aspects. I’m not going to add all the seven code pages here, as the same code structure has to be used, just that we can use other Series types and change the aspect settings as preferred. You will find the ones I have chosen by downloading the complete example at the bottom of the page. In order to follow this article do the same for other pages (Page2.cs, Page3.cs,…) as you have done for the first page.





Now that we have all the Chart styles (pages) we want to appear in our dashboard we’ll go back to the home page to add the necessary code to call each one of the pages and add it to the dashboard.

From here we call each one of the pages generated to be added to each of the cells of the grid; in this way we avoid having to recreate the charts.

First we create the seven DashBoard Charts, just before assigning the content to the grid:



// Create the Chart pages whose contain a specific Chart on each one
DashBoards.Page1 dashchart0 = new DashBoards.Page1();
DashBoards.Page2 dashchart1 = new DashBoards.Page2();
DashBoards.Page3 dashchart2 = new DashBoards.Page3();
DashBoards.Page4 dashchart3 = new DashBoards.Page4();
DashBoards.Page5 dashchart4 = new DashBoards.Page5();
DashBoards.Page6 dashchart5 = new DashBoards.Page6();
DashBoards.Page7 dashchart6 = new DashBoards.Page7();



To be able to navigate between each Content Page (available Chart pages) I’ve decided to create a button and add it to each cell. Some other ways might also work in order to execute part of code once cell is tapped, but this one allows one to do it easily, and also this way, lets us take advantage of the button class functionalities.

We need to create a button for each dashChart. Here’s the code for one of them :



Button button0 = new Button()
{
VerticalOptions = LayoutOptions.FillAndExpand,
HorizontalOptions = LayoutOptions.FillAndExpand,
Command = new Command(() => Navigation.PushAsync(new DashBoards.Page1()))
};



And now we’ll add all the Charts and buttons created to the Grid layout. I’ve chosen some specific rowspan and colspan for some cells, just to look better, but anyone can customise it their way:



// Grid
grid.Children.Add(dashchart0.DashView0, 0,2,0,1);
grid.Children.Add(button0,0,2,0,1);
grid.Children.Add(dashchart1.DashView1, 2,4,0,1);
grid.Children.Add(button1,2,4,0,1);
grid.Children.Add(dashchart2.DashView2, 0, 1);
grid.Children.Add(button2,0, 1);
grid.Children.Add(dashchart3.DashView3, 1, 3, 1, 2);
grid.Children.Add(button3, 1,3,1,2);
grid.Children.Add(dashchart4.DashView4, 3,4,1,3);
grid.Children.Add(button4, 3, 4, 1, 3);
grid.Children.Add(dashchart5.DashView5, 0, 2, 2, 3);
grid.Children.Add(button5, 0, 2, 2, 3);
grid.Children.Add(dashchart6.DashView6, 2, 2);
grid.Children.Add(button6, 2, 2);



The last steps are to modify the App.cs class. This one needs to call the Home.cs content page :



public App()

{
// The root page of your application
MainPage = new NavigationPage(new Home());
}



We’ve also to modify the MainPage.xaml.cs page in order for it to work fine on WinPhone :



public MainPage()
{
InitializeComponent();

Forms.Init();
Content = new TeeChartDashBoards.Home().ConvertPageToUIElement(this);
}



Now we’re going to try to do a build for all the projects, run the app on each platform (IOS, Android y WinPhone) and see the results.



The source code of this example can be downloaded from the Steema GitHub page.



The result should look like:

grid



Read More

Theme persistence

2015 brings some aesthetic improvements for TeeChart VCL/FMX and .NET versions with the intention to make it easier for our users to create visually appealing charts. In this article I’m going to speak about different aspects about new theme usage and possibilities in TeeChart VCL/FMX to accomplish that objective. The concept and the result is almost the same in TeeChart .NET. The only differences are mostly internal and hence transparent to the user. We’ve started by creating two new themes: Lookout and Andros, with their associated color palettes: Lookout and Seawash respectively. This is how those themes look when displaying the full color palette or single color series:
LookoutExample2
Lookout theme example with one single color series
LookoutExample
Lookout theme example showing all the colors in the so called Lookout palette
SeaWashExample
Andros theme example showing all the colors in the associated Seawash palette
AndrosExample
Andros theme example showing a series with one single color from the Seawash palette.
However, this is only the tip of the iceberg because new themes also come with more theme related internal functionality. That is, when a custom theme is applied to a chart, new objects (series, axes and tools) added to it will also inherit the aspect of those themed objects which already exist in the chart. This didn’t occur before. So, for example, if you add a new series to a chart with one of those themes, series in in the chart will perpetuate their settings to additional series added afterwards. An example can be seen in the chart below, an additional series to a chart with the Andros theme will set the series marks to be exactly in the same format without having to perform any custom setting by the user.
Andros2Series
All series in this chart share series marks custom settings without the need of any specific code.
In the VCL/FMX version this applies to series, tools and custom axes, for now. Going even further, users can add their own themes by exporting the charts they created to the TeeChart native template  format (.tee files). There’s just one thing they should bear in mind is that for series to be “themed” they should be of a special type in the custom theme file, TThemedSeries. For example:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
  //Add themed series
  Chart1.AddSeries(TThemedSeries.Create(Self)).FillSampleValues;

  for i:=0 to Chart.SeriesCount-1 do
  begin
    Chart[i].Marks.Arrow.Visible:=False;
    Chart[i].Marks.Transparent:=True;
    Chart[i].Marks.Font.Color:=clWhite;
    Chart[i].Marks.Font.Name:='Verdana';
    Chart[i].Marks.Font.Size:=9;
  end;

  //Export theme
  SaveTeeToFile(Chart1, SourceFolder + 'TeeAndrosTheme.tee');
  //Add themed series
  Chart1.AddSeries(TThemedSeries.Create(Self)).FillSampleValues;

  for i:=0 to Chart.SeriesCount-1 do
  begin
    Chart[i].Marks.Arrow.Visible:=False;
    Chart[i].Marks.Transparent:=True;
    Chart[i].Marks.Font.Color:=clWhite;
    Chart[i].Marks.Font.Name:='Verdana';
    Chart[i].Marks.Font.Size:=9;
  end;

  //Export theme
  SaveTeeToFile(Chart1, SourceFolder + 'TeeAndrosTheme.tee');
Existing series in the chart can be switched to TThemedSeries using the self-explanatory ChangeSeriesType method. Once the custom custom .tee templates are ready, they can be applied using TThemeList.Apply method from TeeThemes unit, for example:
1
TThemesList.Apply( DestinationChart, 'MyChart.tee' );
TThemesList.Apply( DestinationChart, 'MyChart.tee' );
Worth noting that functionality described in this article is intended to be spread across all TeeChart versions in following releases throughout the year so stay tuned as new product updates start rolling out.

Read More

TeeChart NET for iOS and Xamarin.iOS Unified API

As you know the TeeChart NET for iOS have been available since the first MonoTouch version created by Xamarin team. The TeeChart product allows to add professional Charts to your apps easily.

With a very few lines of code you can create the Chart, customize it, set a DataSource for the data and add as a View to the app. You just need to reference to the TeeChart.IOS dll and start working with it. Here you can find an article which shows how to display data from SQLite database into the Chart. This all using a Classic Xamarin iPnone project and the MonoTouch API.

Now Xamarin has introduced the new Xamarin.iOS Unified API. This new api allow to support 32 and 64 bit applications with the same binary. See more info about the Unified API here.

In order to continue supporting all the available Xamarin options, Steema has prepared the new TeeChart NET for Xamarin.iOS Unified version. Now both (the Classic and UInified versions) are included into the TeeChart NET for Xamarin.iOS product, so you can decide which one to use depending on your needs.

You can download the new installer at the customers download page or at the Evalutation versions page.

Here I’m going to show how to create a small dashboard application which uses several Charts on it by using the new Xamarin.iOS Unified and the TeeChart.iOS.Unified versions.

All from the Xamarin Studio IDE.

1) Creating the new Xamarin.iOS app from Xamarin Studio :
Open Xamarin Studio and go to File -> New -> Solution and then select c# -> iOS -> Unified API -> iPhone -> Single View Application.

TeeChartNET_IOS_Unified_1
2) Adding the TeeChart NET for Xamarin.iOS reference to the project :
Right click over the Project references and click “Add references”. Find the TeeChart.iOS.Unified.dll on your hard disk and add it to the the project references.

TeeChartNET_IOS_Unified_2
3) Adding code to the App’s RootViewController :
In order to add some Charts to our application we have to add the using Steema.TeeChart to the top of the unit :

using Steema.TeeChart;
Then create and customize the Charts inside the main View. First we define all the Chart View object we’re going to use, and also an image which will be used to load the logo.


TChart chart1;
TChart chart2;
TChart chart3;
TChart chart4;
UIImageView imageview;

Inside the ViewDidLoad method we’ll create all the Charts, create the Series we want to use and set the specific aspect and features for each Chart. We’ll add the following code :


public override void ViewDidLoad()
{
base.ViewDidLoad();

// Create the Chart View objects
chart1 = new TChart();
chart2 = new TChart();
chart3 = new TChart();
chart4 = new TChart();

// Setting specific frame for each Chart
CoreGraphics.CGRect r1 = this.View.Frame;
r1.Height = r1.Height / 4;
r1.Y = (r1.Height*3)-50;
chart1.Frame = r1 ;

CoreGraphics.CGRect r4 = this.View.Frame;
r4.Height = r4.Height / 4;
r4.Y = (r4.Height*2)-50;
chart4.Frame = r4 ;

CoreGraphics.CGRect r2 = this.View.Frame;
r2.Height = r2.Height / 2 - 50;
r2.Width = r2.Width / 2;
r2.Y = 0;
chart2.Frame = r2 ;

CoreGraphics.CGRect r3 = this.View.Frame;
r3.Height = r3.Height / 2 - 50;
r3.Width = r3.Width / 2;
r3.X = r3.Width;
r3.Y = 0;
chart3.Frame = r3 ;

// Adding Series and features for Chart 1
chart1.Series.Add (new Steema.TeeChart.Styles.Volume ());
chart1.Series [0].FillSampleValues ();
chart1.Aspect.View3D = false;
chart1.Axes.Bottom.Grid.Visible = false;
chart1.Legend.Visible = false;
chart1.Axes.Left.Visible = false;
chart1.Panel.Gradient.Visible = false;
chart1.Panel.Color = UIColor.Black.CGColor;
chart1.Walls.Back.Transparent = true;
chart1.Legend.Visible = false;
chart1.Axes.Bottom.Labels.Font.Color = UIColor.FromRGB (220, 220, 220).CGColor;

// Adding Series and features to the Chart 2
Steema.TeeChart.Styles.CircularGauge gauge1 = new Steema.TeeChart.Styles.CircularGauge ();
chart2.Series.Add (gauge1);
chart2.Axes.Left.Labels.Font.Size = 5;
gauge1.Frame.Width = 15;
gauge1.Ticks.VertSize = 3;
gauge1.Center.Shadow.Visible = false;
gauge1.Axis.AxisPen.Visible = false;
gauge1.FaceBrush.Gradient.Visible = false;
gauge1.FaceBrush.Color = UIColor.FromRGB(220,220,220).CGColor;
gauge1.Hand.Color = UIColor.FromRGB (255, 65, 56).CGColor;
gauge1.Hand.Gradient.Visible = false;
gauge1.Hand.Shadow.Visible = false;
gauge1.Axis.AxisPen.Visible = false;
gauge1.Value = 75;
gauge1.Ticks.VertSize = 3;
chart2.Panel.Gradient.Visible = false;
chart2.Panel.Color = UIColor.Black.CGColor;
chart2.Panel.MarginTop = 0;
chart2.Panel.MarginLeft = 0;
chart2.Panel.MarginBottom = 0;
chart2.Panel.MarginRight = 0;

// Adding Series and features to the Chart 3
Steema.TeeChart.Styles.CircularGauge gauge2 = new Steema.TeeChart.Styles.CircularGauge ();
chart3.Series.Add (gauge2);
chart3.Axes.Left.Labels.Font.Size = 5;
gauge2.Frame.Width = 15;
gauge2.Ticks.VertSize = 3;
gauge2.Axis.AxisPen.Visible = false;
gauge2.Center.Shadow.Visible = false;
gauge2.FaceBrush.Gradient.Visible = false;
gauge2.FaceBrush.Color = UIColor.FromRGB(220,220,220).CGColor;
gauge2.Hand.Color = UIColor.FromRGB (255, 65, 56).CGColor;
gauge2.Hand.Gradient.Visible = false;
gauge2.Hand.Shadow.Visible = false;
gauge2.Axis.AxisPen.Visible = false;
gauge2.Value = 50;
gauge2.Ticks.VertSize = 3;
chart3.Panel.Gradient.Visible = false;
chart3.Panel.Color = UIColor.Black.CGColor;
chart3.Panel.MarginTop = 0;
chart3.Panel.MarginLeft = 0;
chart3.Panel.MarginBottom = 0;
chart3.Panel.MarginRight = 0;

// Adding series and features for the Chart 4
chart4.Series.Add (new Steema.TeeChart.Styles.Line ());
chart4.Series.Add (new Steema.TeeChart.Styles.Line ());
chart4.Series.Add (new Steema.TeeChart.Styles.Line ());
chart4.Series [0].FillSampleValues (20);
chart4.Series [1].FillSampleValues (20);
chart4.Series [2].FillSampleValues (20);
chart4.Series [0].Marks.Visible = false;
chart4.Series [1].Marks.Visible = false;
chart4.Series [2].Marks.Visible = false;
(chart4.Series [0] as Steema.TeeChart.Styles.Line).LinePen.Width = 3;
(chart4.Series [1] as Steema.TeeChart.Styles.Line).LinePen.Width = 3;
(chart4.Series [2] as Steema.TeeChart.Styles.Line).LinePen.Width = 3;
chart4.Aspect.View3D = false;
chart4.Axes.Bottom.Increment = 3;
chart4.Panel.Gradient.Visible = false;
chart4.Panel.Color = UIColor.Black.CGColor;
chart4.Walls.Back.Transparent = true;
chart4.Legend.Visible = false;
chart4.Axes.Left.Visible = false;
chart4.Axes.Botto.Labels.Font.Color = UIColor.FomRGB (220, 220, 220.CGColor;

// Adding Chart views to the main View
this.View.AddSubview(chart1);
this.View.AddSubview(chart2);
this.View.AddSubview(chart3);
this.View.AddSubview(chart4);

// Setting general properties for alll the Charts
chart1.Header.Visible = false;
chart2.Header.Visible = false;
chart3.Header.Visible = false;
chart4.Header.Visible = false;

this.View.BackgroundColor = UIColor.Black;

// Adding logo to the App
imageview = new UIImageView (UIImage.FromBundle ("logo.png"));
CoreGraphics.CGRect rimage = new CoreGraphics.CGRect(95,this.View.Frame.Height-50,this.View.Frame.Width/2-30,50);

imageview.Frame = rimage;
this.View.AddSubview (imageview);
}

Before to try to cmpile and run the app, we’ll have to add the “logo.png” image at the “Resources” folder of our project.

Once this has been done, we can try to run our application, and the result should look like the following image :

TeeChartNET_IOS_Unified_3



You can download the source code of this example here.

Read More

Small tool to create icons and png images for iOS and Android Firemonkey applications

Yet another tool to create the *.png images required by Firemonkey iOS and Android application splash images.

Download source code  (65KB, for Embarcadero RAD Studio XE4 up to XE7)

(Main *.pas unit is aprox 200 lines of code, easy to modify to suit your needs)

Currently this tool generates 42 images of different sizes:

screenshot

Notes:

The sample project uses an FMX 3D form containing a sample “logo”. This can be replaced to use a normal image instead. Using a 3D form might produce better output quality as texts and graphics are regenerated from vector data every time for each icon dimension, instead of stretching a single “big” bitmap.

The *.ico file for Windows projects is created containing a single image.
You can use Gimp or IcoFX to create a multiple ico file using the generated *.png images.

See this great article about creating multi-icon *.ico files for Windows applications from Simon Stuart’s OTAPI.com:

http://otapi.com/2014/09/28/making-windows-icons-for-rad-studio-applications/



The *.icns file for Mac OSX applications is not created as it has several complex requeriments (a shell command line tool must be used in the Mac machine) explained here:

https://developer.apple.com/library/mac/documentation/GraphicsAnimation/Conceptual/HighResolutionOSX/Optimizing/Optimizing.html#//apple_ref/doc/uid/TP40012302-CH7-SW3



Read More
